Lenovo IdeaPad Miix 520 - 20M3003DUK
Lenovo IdeaPad Miix 520
Product code: 20M3003DUK
- 💻Display diagonal: 12.2 inch
- 🔳Processor family: Intel Core i5
- 🔳Processor model: i5-8250U
- 🎮Graphics card: UHD Graphics 620
- 💿Internal storage capacity: 256 GB
- 📡Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
- 🔋Battery capacity: 39 Wh
- ⚖️Weight: 0.88 kg
📊 Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Brand | Lenovo |
| Part Number | 20M3003DUK |
| Release Date | 29 October 2017 |
| Model name | 520 |
| Family | IdeaPad |
| Series | Miix |
| EAN/UPC code | 0192076908608, 192076908608 |
|
|
|
| Design | |
| Device type | Tablet PC |
| Product colour | Grey |
| Colour name | Iron grey |
| Display | |
| Display diagonal | 12.2 inch |
| Display resolution | 1920 x 1200 pixels |
| Touchscreen type | Capacitive |
| Native aspect ratio | 16:10 |
| Touch technology | Multi-touch |
| LED backlight | Yes |
| Panel type | IPS |
| Display brightness | 320 cd/m² |
| Processor | |
| Processor cores | 4 |
| Processor family | Intel Core i5 |
| Processor model | i5-8250U |
| Processor frequency | 1.6 GHz |
| Processor manufacturer | Intel |
| Processor boost frequency | 3.4 GHz |
| Processor generation | 8th gen Intel Core i5 |
| Processor cache | 6 MB |
| Configurable TDP-down frequency | 0.8 GHz |
| Processor lithography | 14 nm |
| Processor threads | 8 |
| Processor cache type | Smart Cache |
| Processor operating modes | 64-bit |
| Processor package size | 42 x 24 mm |
| Thermal Design Power (TDP) | 15 W |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Tjunction | 100 °C |
| Thermal Monitoring Technologies | Yes |
| System bus rate | 4 GT/s |
| Processor codename | Kaby Lake R |
| Conflict-Free processor | Yes |
| PCI Express configurations | 1x2+2x1, 1x4, 2x2, 4x1 |
| Bus type | OPI |
| Stepping | Y0 |
| Processor code | SR3LA |
| Memory | |
| Internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 8 GB |
| Memory clock speed | 2133 MHz |
| Graphics | |
| Graphics card | UHD Graphics 620 |
| Graphics card family | Intel |
| Storage | |
| Internal storage capacity | 256 GB |
| Card reader integrated | Yes |
| Storage media | SSD |
| Compatible memory cards | MicroSD (TransFlash) |
| Audio | |
| Number of built-in speakers | 2 |
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| Speaker power | 1 W |
| Camera | |
| Front camera | Yes |
| Rear camera type | Single camera |
| Rear camera resolution (numeric) | 5 MP |
| Front camera resolution (numeric) | 5 MP |
| Video recording | Yes |
| Rear camera | Yes |
| Network | |
| Bluetooth | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Bluetooth version | 4.1 |
| Mobile network connection | Yes |
| Mobile network generation | 4G |
| 4G standard | LTE |
| WWAN | Installed |
| Ports & interfaces | |
| Combo headphone/mic port | Yes |
| Headphone out | No |
| Microphone in | No |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Performance | |
| Gyroscope | Yes |
| Software | |
| Platform | Windows |
| Operating system installed | Windows 10 Pro |
| Operating system architecture | 64-bit |
| Trial software | McAfee LiveSafe |
| Battery | |
| Battery capacity | 39 Wh |
| Battery life (max) | 8 h |
| Battery technology | Lithium Polymer (LiPo) |
| Battery capacity (Watt-hours) | 39 Wh |
| Number of battery cells | 2 |
| Weight & dimensions | |
| Width | 300 mm |
| Depth | 205 mm |
| Height | 9.9 mm |
| Weight | 0.88 kg |
| Other features | |
| Processor ARK ID | 124967 |
| Processor socket | BGA 1356 |
| Packaging content | |
| Manual | Yes |
| Power | |
| AC adapter power | 45 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
